Industrial-grade dust suppression machines with advanced water mist fog cannon technology for effective air quality management in construction sites, mining operations, stone crushers, and industrial facilities β ensuring CPCB compliance and worker safety.
Request Bulk Quote β
A Dust Suppression Machine is an engineered air-clearing water cannon designed to spray high-density mist over expansive open areas. The machine integrates a heavy-duty axial flow fan blower, a high-pressure water pump, an anti-clogging filter network, and a circumferential ring of micro-atomizing nozzles.
When high-pressure water is forced through the precision nozzles, it atomizes into a fine fog matching the particle diameter of airborne dust (PM2.5 / PM10). Because the micro-droplets match the physical scale of dust grains, they aggregate upon impact. The weighted particles settle rapidly to the ground via gravity, effectively "washing" the air without creating mud pools or soaking equipment.
These machines are also commonly known as:
Dust Suppression Machines are widely used in:
In high-volume quarrying, concrete batching, and demolition projects, conventional water tanker hosing wastes vast amounts of water while leaving airborne dust suspended. Modern dust suppression cannons deliver distinct operational advantages for environmental compliance and cost efficiency.
| Parameter | Specification |
|---|---|
| Product Name | Heavy-Duty Dust Suppression Machine / Fog Cannon |
| Mist Throw Range | 30m, 50m, 60m, 75m, 100m+ (Custom throw ranges available) |
| Droplet Size | 10 - 50 Microns (Ultra-fine atomized fog) |
| Operating Pressure | 70 to 100 Bar High-Pressure Booster System |
| Fan Motor Power | 5.5 HP - 20 HP Heavy-Duty Three-Phase Axial Motor |
| Water Pump Power | 2 HP - 7.5 HP High-Pressure Pump |
| Nozzle Configuration | 18 - 48 Nos. Stainless Steel / Brass Anti-Clogging Nozzles |
| Horizontal Rotation | 0Β° to 340Β° Motorized Automated Oscillation |
| Vertical Elevation | 0Β° to 60Β° Adjustable Tilt Angle |
| Body Construction | Heavy-Grade Mild Steel (MS) / Stainless Steel (SS) |
| Mounting Options | Trolley-Mounted, Skid-Mounted, Truck-Mounted, Terrace/Tower-Mounted |
| Control Grade | Manual / Semi-Automatic / Fully Automatic with Wireless Remote |
Dust Suppression Machines are available in four distinct mounting setups to suit varied mobility and placement requirements across India.
Applications
Applications
Applications
Applications
Applications
Applications
Dust Suppression Machines are deployed across diverse high-dust environments throughout India for effective air quality management.
| Industry Sector | Primary Application | Key Benefit |
|---|---|---|
| Construction & Infrastructure | Excavation dust, high-rise construction clouds | Environmental compliance |
| Demolition & Recycling | Concrete dust plumes, structural crushing | Heavy dust control |
| Mining & Material Stockpiles | Open-cast mining, coal stockyards | Worker health protection |
| Stone Crushers & Quarries | Silica and fine stone dust suppression | Occupational safety |
| Cement & Power Plants | Raw material intake, fly ash control | Emission reduction |
| Municipal Corporations | Urban smog reduction, road dust | Air quality improvement |
| Aggregate Stockyards | Material transfer dust suppression | Dust prevention |
| Infrastructure Projects | Flyover, highway construction | Dust management |
Operating a dust suppression machine requires proper positioning, connection, and systematic engagement of the atomization and fan systems.
Surya Engineering subjects every manufactured Dust Suppression Machine to strict quality assurance protocols before site dispatch to ensure long operational life.
| Test Type | Objective | Performance Verification |
|---|---|---|
| Hydrostatic Pressure Test | Verifies consistent 70-100 bar pressure | No leakage or seal failure |
| Droplet Pattern Inspection | Confirms uniform micro-fog atomization | 10-micron consistency |
| Throw Range Calibration | Validates fan air-velocity | Guaranteed 30m to 100m+ delivery |
| Motor & Electrical Safety Test | Electrical insulation and load checks | Safety certification compliance |
| Continuous Run Vibration Test | Full load operation verification | Low vibration, thermal stability |
| Nozzle Clogging Test | Tests anti-clogging filter system | Consistent mist output |
| Noise Level Test | Measures operational noise | Within acceptable limits |
Every Dust Suppression Machine manufactured at Surya Engineering undergoes systematic quality verification to ensure reliable performance across construction sites, mining operations, and industrial facilities nationwide.
Quality Control Benefits:
Surya Engineering is an established ISO 9001:2015 certified manufacturer of construction equipment and environmental control machinery based in Mumbai, Maharashtra. With extensive engineering experience, we have built a national reputation for quality manufacturing, technical performance, and robust field support. When you partner with Surya Engineering, you deal directly with the OEM manufacturer.
Surya Engineering manufactures and dispatches Dust Suppression Machines directly from our Mumbai production facilities to major construction, mining, and industrial centers across India. Our factory-direct supply network ensures prompt dispatch and lifetime support.
30mβ100m+ Mist Throw Range Β· 10-50 Micron Ultra-Fine Droplets Β· CPCB Compliant Β· Heavy-Duty OEM Manufactured Β· PAN India Supply & Support
Request a Quote β
